The Creality Raptor Pro is a professional-grade 3D scanner combining three scanning modes - Blue Light (7 parallel laser lines), Blue Light (22 cross laser lines), and NIR infrared binocular structured light - in a single device. With accuracy up to 0.02mm and a scanning speed of 660,000 points/s, it delivers industrial-level precision for reverse engineering, quality control, and digital fabrication.
Key Features
- 22 cross blue laser lines + 7 parallel laser lines + NIR structured light
- Accuracy up to 0.02mm (blue light) / 0.075mm (NIR)
- Scanning speed: up to 660,000 points/s (blue light) | 3,580,000 points/s (NIR)
- Volumetric accuracy: 0.02 + 0.08mm/m
- Scan objects from 5mm to 4000mm
- Scans black and metallic surfaces without sprays
- Wireless scanning supported
- 24-bit full-color scanning via NIR mode
Technical Specifications
| Mode | 7 Parallel Lines | 22 Cross Lines | NIR |
|---|---|---|---|
| Accuracy | Up to 0.02mm | Up to 0.02mm | Up to 0.075mm |
| Volumetric Accuracy | 0.02+0.08mm/m | 0.02+0.08mm/m | 0.075+0.1mm/m |
| Scanning Speed | 420,000 pts/s | 660,000 pts/s | 3,580,000 pts/s |
| Working Distance | 160–400mm | 200–550mm | 170–1000mm |
| Capture Range | 270×170mm @300mm | up to 397×290mm @500mm | 630×550mm @1000mm |
| Outdoor Scanning | < 50,000 lux | < 10,000 lux | < 30,000 lux |
System Requirements
Windows: Windows 10/11 (64-bit), i7 Gen10+ (min: i7 Gen7), Nvidia GPU 8GB VRAM+ (min: 6GB), 32GB RAM+ (min: 16GB)
macOS: macOS 11.7.7+, Apple M1/M2/M3, 16GB RAM+
In the Box
- Creality Raptor Pro 3D Scanner × 1
- USB-C cable × 1
- Power adapter × 1
- Calibration board × 1
- Carrying case × 1
